Gree Lomo Series Residential Air Conditioning 9000 12000 18000 22000 Btu Wholesale Wall Mounted Split Air Conditioner Electric
You are here: Home » Products » Gree Lomo Series Residential Air Conditioning 9000 12000 18000 22000 Btu Wholesale Wall Mounted Split Air Conditioner Electric

loading

Gree Lomo Series Residential Air Conditioning 9000 12000 18000 22000 Btu Wholesale Wall Mounted Split Air Conditioner Electric

Gree Lomo Series Residential Air Conditioning 9000 12000 18000 22000 Btu Wholesale Wall Mounted Split Air Conditioner Electric
Availability:
Quantity:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
Gree Lomo Series Residential Air Conditioning 9000 12000 18000 22000 Btu Wholesale Wall Mounted Spli
Product Description
Product Paramenters
MODEL
GMC09QB-K3NNB2A
GMC12QC-K3NNB2A
GMC18QD-K3NNB2A
GMC24QE-K3NNB2A
Function
Cooling
Cooling
Cooling
Cooling
Capacity-Cooling/BTU
9500
12000
18000
22000
EER
3.21
3.21
3.21
3.21
Energy Class
A
A
A
A
Power Supply
1PH,220-240V,50HZ
1PH,220-240V,50HZ
1PH,220-240V,50HZ
1PH,220-240V,50HZ
Power Input-Cooling/W
870
1095
1630
2010
Rated Current-Cooling/A
5.9
9
14
17
Airflow Volume-Indoor
530/490/430/330
650/560/480/300
900/850/750/600
1200/1000/800/650
Sound Pressure Level-Indoor
39/36/32/26
41/37/33/29
47/43/40/36
49/45/40/37
Outline Dimension-W*H*D/mm
790*275*200
845*289*209
970*300*224
1078*325*246
Package Dimension-W*H*D/mm
866*357*271
921*379*281
1041*383*320
1148*413*350
Net Weight/Gross Weight-Indoor/kg
9/11
10.5/12.5
13.5/16.5
17/20.5
Sound Pressure Level-Outdoor
51
52
53
55
Piping Connection-Gas/mm
φ9.52
φ12
φ12
φ16
Piping Connection-Liquid/mm
φ6
φ6
φ6
φ6
Outline Dimension
776*540*320
848*540*320
899*596*378
913*680*378
-W*H*D/mm
Package Dimension-W*H*D/mm
823*595*358
881*595*363
948*645*420
997*740*431
Net Weight/Gross Weight-Outdoor/kg
26.5/29
31.5/34
45/48
52/56
Loading Quantity-40'GP/sets
224
192
156
120
Loading Quantity-40'HQ/sets
262
240
179
140
表格宽度最宽为750，超过750的部分及内容均无法展示
