48V DC Inverter Solar Panel (Gree): Designed for Split Air Conditioner System, Suitable for Off-Grid Household Solar Conditioner

48V DC Inverter Solar Panel (Gree): Designed for Split Air Conditioner System, Suitable for Off-Grid Household Solar Conditioner

Quantity:
Availability:





Inquire Add to Basket

solar panel DC 48V household air conditioner home split air conditioner ACDC air conditioner

Product Description

Details Images

Features:

1.100% off grid
2.DC 48V battery powered
3. Battery low voltage protection
4.DC driven high efficiency
5.Wide operating temperature (-10℃ to 58℃)

Product Introduction:

Introducing the 100% Off Grid 48V DC Inverter Solar Air Conditioner which uses no electricity effectively reducing operating costs by up to 100% during the day and night. The 100% Off Grid Unit uses a combination of Solar Power and Battery Storage.

Product advantages:

100% DC Inverter = No Wasted Energy
√ 12,000 24,000 BTU Capacity.
√ All DC = No Inverter equipment needed.
√ 48v Solar/Battery Power
√ Variable Capacity
√ Anti-Corrosion Technology
√ Eco-Friendly R410a Refrigerant
√ Washable Filters
√ Digital Wireless Remote
√ Quiet Indoor Unit(As Low As 26dB)

Product Paramenters

Specification
Hybrid Full DC inverter Solar Air Conditioner Split type
Parameter		Unit	Value	Value
Model		--	12000BTU/1.0TON	18000BTU/1.5TON
Application Area		m2	14～24	21～30
Power Supply	Rated Voltage	V-	48.00	48.00
Power Supply	Input Voltage range	V-	42-58	42-58
Solar Dc Current	Max.Current	A	25.00	35.00
Rated Current	Cooling Rate Current	A	18.50	29.20
Rated Current	Heating Rate Current	A	18.65	27.50
Rated Power	Cooling Rate Power	W	855.00	1350.00
Rated Power	Heating Rate Power	W	895.00	1320.00
Min. Cooling Power Input		W	175.00	236.00
Max. Cooling Power Input		W	1200.00	1550.00
Cooling Capacity		W	3500.00	5000.00
Cooling Capacity		Btu/h	11970.00	17100.00
Min. Cooling Capacity		W	1400.00	1600.00
Min. Cooling Capacity		Btu/h	4786.60	5470.40
Max. Cooling Capacity		W	3900.00	5350.00
Max. Cooling Capacity		Btu/h	13334.10	18291.65
EER		W/W	4.10	3.72
Indoor Unit	Indoor Unit Model	--	SHY12/I-YK	SHY18/I-YK
	Fan Type	--	Cross-flow	Cross-flow
	Indoor Unit Air Flow Volume	m3/h	690.00	980.00
	Set Temperature Range	℃	16~32	16~32
	Set Temperature Range	℉	61～90	61～90
	Sound Pressure Level(SH/H/L/SL)	dB (A)	24-37-41	30-42-45
	Dimension (W×H×D)	mm	895300205	1000x310x240
	Dimension of Package(W×H×D)	mm	965370275	1075x385x310
	Stacked Layers	－	7	7
	Net Weight	kg	11.00	13.00
	Gross Weight	kg	13.00	15.00
Outdoor Unit	Outdoor Unit Model	--	SHY12/O-YK	SHY18/O-YK
	Compressor Trademark		HIGHLY	HIGHLY
	Compressor Model	--	GSX102SKQA6JL	GSD113RKQF6JV6B
	Compressor Type	--	Rotary	Rotary
	Permissible Excessive Operating Pressure for the Discharge Side	MPa	4.3	4.3
	Permissible Excessive Operating Pressure for the Suction Side	MPa	2.5	2.5
	Maximum Allowable Pressure	MPa	4.3	4.3
	Cooling Operation Ambient Temperature Range	℃	0~55	0~55
	Sound Pressure Level	dB (A)	52.00	54.00
	Dimension (W×H×D)	mm	797556336	874559368
	Dimension of Package(W×H×D)	mm	855600367	913604396
	Stacked Layers		4.00	4.00
	Net Weight	kg	27.00	31.00
	Gross Weight	kg	30.00	34.00
	Refrigerant	--	R32	R32
	Refrigerant Charge	g	800.00	950.00
